We are occupied with offering a far reaching scope of High Efficiency Coalescing Filters PVI/PVA to clients. Our clients can profit these items in various determinations from us.
Download PDF
Application :
This PVI / PVA High efficiency coalescing filters are available ¡n different flow ratings from 127 up to 307 scfm and in pipe sizes (G1) to (G2). It is designed for applications where all
solid particles of upto 1.0 / 0.01 micron size or larger are to be removed from the air supply alongwith oil and water aerosols upto 0.5/0.01 mg/rn3. These filters are so efficient that as the
air is directed through the wrapped filtering media, solid contamination of 1.0/0.01 p size are trapped by Interception, Inertial Impact and Diffusion at low velocities, aerosols are coalesced to form liquid droplets which are permanently removed from the air stream and captured into the sump. Material of construction being in S.S. 304, it does not require painting or powder coating.
Features :
* Ideal for Pharma Industry, Chemical Industries.
* Low Pressure Drop.
* Initial low cost.
* No tools required for servicing.
